- Model identifier
- KM 2010
- Manufacturer material number
- 07113300
- EAN number
- 4002514414041
- Dimensions (H x W x D) in mm
- 90 x 650 x 520
- Dimensions (W x D) in mm
- 650 x 90 x 520
- Dimensions in mm (width)
- 650
- Dimensions in mm (height)
- 90
- Dimensions in mm (depth)
- 520
- Cut-out dimensions (W x D) with surface-mounted installation in mm
- 560 mm x 480 mm
- Casing height incl. connection box in mm
- 54
- Cutout dimensions in mm (width) with surface-mounted installation
- 560 mm
- Cutout dimensions in mm (depth) with surface-mounted installation
- 480 mm
- Weight in kg
- 13
- Total rated load in kW
- 7.100
- Position of gas connection
- Hinten links
- Voltage in V
- 220 - 240
- Frequency in Hz
- 50 - 60
- Length of supply lead in m
- 1.4
