Cooker hoods - DA 6698 W Purist. Ed.6000 Obsidian black - 1

Wall mounted cooker hood

DA 6698 W Purist. Ed.6000 Obsidian black

Name: DA 6698 W Purist. Ed.6000
Brand: Miele
SKU: 12050600
Price: 2779 GBP
Availability: InStock

with energy-efficient LED lighting and touch controls for simple operation.

Product data sheet

Colour:Obsidian black

£2,779.00

Delivery from £20. Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630.

Additional services

Product details

Family design – based on Miele built-in appliances
Unique user convenience –Con@ctivity
Powerful – 640 m3/h in Booster level
Energy-efficient and quiet - powerfulECO motor
Pleasantly quiet –Miele Silence package

Product data sheet

Wall mounted cooker hood

Type of air guideCan be retrofitted

ColourObsidian black

Electronic controls

Booster levels1

Silence package

Energy efficiency class (A+++ to D)A++

Annual energy consumption in kWh/year24.60

Fluid dynamic efficiency classA

Lighting efficiency classA

Grease filtering efficiency classA

PowerManagement system

Number of dishwasher-safe stainless steel grease filters (10-ply)3

Number x W3 x 3 W

Light intensity in Lx670 lx

Colour temperature in K3500 Kelvin

Dual-action blower

DC motor

Air throughput in Level 1 (m³/h) according to EN 61591200

Air throughput in Level 2 (m³/h) according to EN 61591300

Air throughput in Level 3 (m³/h) according to EN 61591400

Air throughput in booster level 1 (m³/h)640

Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-336

Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-344

Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-352

Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-363

Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1321

Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1329

Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1337

Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1348

Air throughput in Level 1 (m³/h) according to EN 61591110

Air throughput in Level 2 (m³/h) according to EN 61591185

Air throughput in Level 3 (m³/h) according to EN 61591315

Air throughput in Booster level 1 (m³/h) according to EN 61591460

Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-345

Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-353

Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-363

Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-372

Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1330

Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1338

Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1348

Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1357

Safety shut-off

Single-ply safety glass (ESG)

Overall height for vented and external in in. (mm)710

Overall height for extraction mode and external mode cooker hoods in mm1030

Overall height for recirculation in in. (mm)840

Overall height for recirculation mode cooker hoods in mm1160

Canopy width in in. (mm)898

Canopy height in in. (mm)85

Depth of hood canopy in in. (mm)500

Minimum height above electric hobs in mm450

Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm650

Net weight in kg26

Length of supply lead in m1.50

Standard plug fitted

Total rated load in kW0.09

Voltage in V230

Fuse rating in A10

Frequency in Hz50

Number of phases1

Extraction ducting connection at top

Extraction connection at top and rear

Diameter of extraction ducting connection in mm150

Telescopic chimney

Non-return flap

EAN4002516585770

What's included

Easy to use and effective against grease

Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.

Performance and convenience as standard

Silence

Efficient and quiet: the fan is effectively insulated with special soundproofing mats.

The heart of every cooker hood

ECO motor

Powerful and economical: the DC motor saves up to 50 % electricity compared with conventional motors.
