  • Miele - DA 6698 W Purist. Ed.6000 Stainless steel – Cooker hoods - 1
Wall mounted cooker hoodDIAMOND

DA 6698 W Purist. Ed.6000 Stainless steel

with energy-efficient LED lighting and touch controls for simple operation.
Colour:Stainless steel
Product data sheet
sale price£2,929.00
1
Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630




Product details

  • Family design – based on Miele built-in appliances
  • Unique user convenience –
    Con@ctivity
  • Powerful – 640 m3/h in Booster level
  • Energy-efficient and quiet - powerful
    ECO motor
  • Pleasantly quiet –
    Miele Silence package
  • View manufacturer details:
  • You will find more information about product data and your rights under the EU Data Acthere
  • Safety Information

Product data sheet

Wall mounted cooker hood
Type of air guide Can be retrofitted
Colour Stainless steel
Con@ctivity Yes
Electronic controls
Booster levels 1
Silence package
Energy efficiency class (A+++ to D) A++
Annual energy consumption in kWh/year 24.6
Fluid dynamic efficiency class A
Lighting efficiency class A
Grease filtering efficiency class A
ECO motor (DC motor)
PowerManagement system
Number of dishwasher-safe stainless steel grease filters (10-ply) 3
Number x W 3 x 3 W
Light intensity in Lx 670 lx
Colour temperature in K 3500 Kelvin
Dual-action blower
DC motor
Air throughput in Level 1 (m³/h) according to EN 61591 200
Air throughput in Level 2 (m³/h) according to EN 61591 300
Air throughput in Level 3 (m³/h) according to EN 61591 400
Air throughput in Booster level 1 (m³/h) according to EN 61591 640
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 36
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 44
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 52
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 63
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 21
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 29
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 37
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 48
Air throughput in Level 1 (m³/h) according to EN 61591 110
Air throughput in Level 2 (m³/h) according to EN 61591 185
Air throughput in Level 3 (m³/h) according to EN 61591 315
Air throughput in Booster level 1 (m³/h) according to EN 61591 460
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 45
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 53
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 63
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 72
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 30
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 38
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 48
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 57
Safety shut-off
Single-ply safety glass (ESG)
Canopy dimensions (W x H x D) in mm 898 x 85 x 500
Overall height for vented and external in in. (mm) 710
Overall height for extraction mode and external mode cooker hoods in mm 1030
Overall height for recirculation in in. (mm) 840
Overall height for recirculation mode cooker hoods in mm 1160
Canopy width in in. (mm) 898
Canopy height in in. (mm) 85
Depth of hood canopy in in. (mm) 500
Minimum height above electric hobs in mm 450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm 650
Net weight in kg 26
Length of supply lead in m 1.5
Standard plug fitted
Total rated load in kW 0.089
Voltage in V 230
Fuse rating in A 10
Frequency in Hz 50
Number of phases 1
Extraction ducting connection at top
Diameter of extraction ducting connection in mm 150
Telescopic chimney
Non-return flap
EAN 4002516585275

What's included

Non-return flap
  • Automatic operation for intelligent fan control

    Automatic operation for intelligent fan control

    Con@ctivity

    Innovative convenience: the cooker hood reacts automatically to settings on the hob.

  • Easy to use and effective against grease

    Easy to use and effective against grease

    Stainless steel grease filters (10-layer)

    Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.

  • Performance and convenience as standard

    Performance and convenience as standard

    Silence

    Efficient and quiet: the fan is effectively insulated with special soundproofing mats.

  • The heart of every cooker hood

    The heart of every cooker hood

    ECO motor

    Powerful and economical: the DC motor saves up to 50 % electricity compared with conventional motors.

Features

Easy to use and effective against grease
Easy to use and effective against grease

Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Performance and convenience as standard
Performance and convenience as standard

Silence

Efficient and quiet: the fan is effectively insulated with special soundproofing mats.

User convenience

Automatic operation for intelligent fan control
Automatic operation for intelligent fan control

Con@ctivity

Innovative convenience: the cooker hood reacts automatically to settings on the hob.

Efficiency

The heart of every cooker hood
The heart of every cooker hood

ECO motor

Powerful and economical: the DC motor saves up to 50 % electricity compared with conventional motors.

Safety

Always on the safe side
Always on the safe side

Safety switch-off

Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.

Matching products and accessories

Wall box
DMK 150-1

Wall box

for extraction.

£299.00
Aluminium vent hose
DAS 150

Aluminium vent hose

flexible vent duct.

£89.49
Recirc. conversion kit for wall hood
DUW 20

Recirc. conversion kit for wall hood

to convert wall mounted cooker hoods from air extraction to recirculation mode.

£79.00
Roof vent
DDF 125

Roof vent

for extraction.

£262.49
Active AirClean charcoal filter
DKF 16-P

Active AirClean charcoal filter

for the Miele DA 7006 D cooker hood.

£157.59
Active AirClean charcoal filter
DKF 17-P

Active AirClean charcoal filter

for the Miele DA 700x D cooker hood.

£281.29
MicroCloth kit, 3 pieces
GP MI S 0031 W

MicroCloth kit, 3 pieces

For best cleaning results and safe use.

£17.39
Multi-purpose microfibre cloth, qty 1
GP MI X 0011 W

Multi-purpose microfibre cloth, qty 1

For best cleaning results and safe use.

£8.69

Downloads

UK declaration of conformity
PDF
Downloads
Installation plan
PDF
Downloads
Operating instructions/Installation instructions
PDF
Downloads
Product sheet
PDF
Downloads
Warranty conditions
PDF
Downloads
dwg
ZIP
Downloads
fbx
ZIP
Downloads
ifc
ZIP
Downloads
rfa
ZIP
Downloads
rvt
ZIP
Downloads
Energy label
PDF
Downloads
Energy label
PNG
Downloads
Product fiche
PDF
Downloads
Energy label
PDF
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000009/200000982/20000098271.png
Descriptions
DA 6698 W, CLST (Installation drawing)
1. Extraction, 2. Recirculation, 3 Ventilation grilles at the top for recirculation, 4. + 5. Vent cut-out positions (Area 5 not required for recirculation)
