Wall mounted cooker hood
Type of air guideCan be retrofitted
Active charcoal filter (order separately)DKF 29 charcoal filter
ColourBronze patina
Edge extraction
Miele@home
Automatic function Con@ctivity
Electronic controls
Touch-on-glass controls
ControlsSmartControl
ON/OFF switch
Power levels (number without Booster level)3
Booster levels2
Run-on time 5/15 min.
Grease filter saturation indicator
Grease filter saturation indicator
Active charcoal filter saturation indicator
Silence package
Easy-to-clean canopy interior – CleanCover
Energy efficiency class (A+++ to D)A++
Annual energy consumption in kWh/year28.20
Fluid dynamic efficiency classA
Lighting efficiency classA
Grease filtering efficiency classD
PowerManagement system
Easy-to-clean canopy interior – CleanCover
Number of dishwasher-safe stainless steel grease filters (10-ply)2
LED
Number x W1 x 3,2 W
Light intensity in Lx260 lx
Colour temperature in K3500 Kelvin
Dimmer function
Dual-action blower
DC motor
Air throughput in Level 1 (m³/h) according to EN 61591215
Air throughput in Level 2 (m³/h) according to EN 61591315
Air throughput in Level 3 (m³/h) according to EN 61591415
Air throughput in booster level 1 (m³/h)660
Air throughput in booster level 2 (m³/h)875
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-338
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-345
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-350
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-361
Sound power in Booster level 2 (dB(A) re 1 pW) acc. to EN 60704-368
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1324
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1331
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1336
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1347
Sound pressure in Booster level 2 (dB(A) re 20 µPa) acc. to EN 60704-2-1354
Air throughput in Level 1 (m³/h) according to EN 61591175
Air throughput in Level 2 (m³/h) according to EN 61591275
Air throughput in Level 3 (m³/h) according to EN 61591430
Air throughput in Booster level 1 (m³/h) according to EN 61591625
Air throughput in Booster level 2 (m³/h) according to EN 61591720
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-346
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-353
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-364
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-373
Sound power in Booster level 2 (dB(A) re 1 pW) acc. to EN 60704-376
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1332
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1339
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1350
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1359
Sound pressure in Booster level 2 (dB(A) re 20 µPa) acc. to EN 60704-2-1362
Safety shut-off
Single-ply safety glass (ESG)
Overall height for vented and external in in. (mm)830
Overall height for extraction mode and external mode cooker hoods in mm1210
Overall height for recirculation in in. (mm)420
Overall height for recirculation mode cooker hoods in mm420
Canopy width in in. (mm)898
Canopy height in in. (mm)420
Depth of hood canopy in in. (mm)381
Minimum height above electric hobs in mm450
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm650
Net weight in kg18
Length of supply lead in m1.30
Standard plug fitted
Total rated load in kW0.22
Voltage in V230
Fuse rating in A10
Frequency in Hz50
Number of phases1
Extraction ducting connection at top
Extraction connection at top and rear
Diameter of extraction ducting connection in mm150
Non-return flap
EAN4002516802921
