Induction hob with integrated vapour extraction

KMDA 7473 FL-A Silence

with Silence motor and 2 Flex zones for extraction mode


sale price£3,399.00




Product details

  • The quietest TwoInOne from Miele –Silence motor
  • Ample space – 4 large cooking zones incl.2 Flex zones
  • Automatic fan power regulation –Con@ctivity
  • Compact control using the numerical display –ComfortSelect Plus
  • Suitable for flexible extraction installations

Downloads

Warranty conditions
PDF
Downloads
Operating instructions/Installation instructions
PDF
Downloads
Product sheet
PDF
Downloads
rfa
ZIP
Downloads
dwg
ZIP
Downloads
ifc
ZIP
Downloads
rvt
ZIP
Downloads
fbx
ZIP
Downloads
Product fiche
PDF
Downloads
Energy label
PNG
Downloads
Energy label
PDF
Downloads
Energy label
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000018/200001869/20000186953.png
Descriptions
KMDA7272FL, KMDA7473FL - Installation drawing
1) Front, 2) Removable drip tray, 3) Cleaning flap, 4) Mains connection box with mains connection cable, L = 1600 mm, 5) Worktop thickness, Exhaust air and guided recirculation mode: ≥10 mm, Plug&Play operation: ≥10 mm - ≤40 mm
Downloads
https://media.miele.com/images/2000018/200001869/20000186952.png
Descriptions
KMDA7272FL, KMDA7473FL - flush - Installation drawing
1) Front, 2) removable drip tray, 3) cleaning flap, 4) Mains connection box with mains connection cable, L = 1600 mm, 5) Step milling natural stone worktop, 6) Wooden strip 12 mm (not included in delivery), 7) Worktop thickness, Exhaust air and guided recirculation mode: ≥10 mm, Plug&play operation: ≥10 mm - ≤40 mm
Downloads
https://media.miele.com/images/2000018/200001870/20000187038.png
Descriptions
KMDA7272FL/FR, KMDA7473FL/FR, Exhaust air (Installation drawing)
Installation drawings
Downloads
https://media.miele.com/images/2000018/200001872/20000187296.png
Descriptions
KMDA7272FL, KMDA7473FL - Side view flush, Plug&Play - Installation drawing
①A minimum distance of 25 mm must be maintained for routing the exhaust air duct between the cabinet wall and an adjacent room wall or furniture., ②The removable collection tray and the cleaning flap must be accessible after installation., ③The cross-section of the ventilation opening must be at least 425 cm².
Downloads
https://media.miele.com/images/2000018/200001872/20000187297.png
Descriptions
KMDA7272FL, KMDA7473FL - Side view lying on top, Plug&Play - Installation drawing
①A minimum distance of 25 mm must be maintained for routing the exhaust air duct between the cabinet wall and an adjacent room wall or furniture., ②The removable collection tray and the cleaning flap must be accessible after installation., ③The cross-section of the vent opening must be at least 425 cm².
Downloads
https://media.miele.com/images/2000018/200001873/20000187300.png
Descriptions
KMDA7272FL, KMDA7473FL - Side view flush+X, Plug&Play - Installation drawing
①A minimum distance of 25 mm must be maintained for routing the exhaust air duct between the carcase wall and an adjacent room wall or furniture. If the carcase rear wall is <gt/> 555 mm from the worktop front, the Plug&Play adapter must be extended with a supplementary set from Miele., ②The removable drip tray and the cleaning flap must be accessible after installation., ③The cross-section of the vent opening must be at least 425 cm²., , x Dimension by which the worktop depth is greater than 600 mm.
Downloads
https://media.miele.com/images/2000018/200001873/20000187301.png
Descriptions
KMDA7272FL, KMDA7473FL - Side view lying on top+X, Plug&Play - Installation drawing
①A minimum distance of 25 mm must be maintained for routing the exhaust air duct between the carcase wall and an adjacent room wall or furniture. If the carcase rear wall is <gt/> 555 mm from the worktop front, the Plug&Play adapter must be extended with a supplementary set from Miele., ②The removable drip tray and the cleaning flap must be accessible after installation., ③The cross-section of the vent opening must be at least 425 cm²., , x Dimension by which the worktop depth is greater than 600 mm.
Downloads
https://media.miele.com/images/2000018/200001868/20000186838.png
Descriptions
KMDA7473FL/FR - Operating options
✓✓ Possible, ✓ Possible - further accessories necessary, - Programming must be changed - further accessories necessary
Downloads
https://media.miele.com/images/2000018/200001879/20000187989.png
Descriptions
KMDA7272FL/FR, KMDA7473FL/FR -Installation variant 3 Basis - drawing
1) DFK-AK 90, 2) DFK-R 1000, 3) DFK-BV 90, 4) DFK-BH 90
Downloads
https://media.miele.com/images/2000018/200001879/20000187988.png
Descriptions
KMDA7272FL/FR, KMDA7473FL/FR - Installation variant 2 Basis - drawing
1) DFK-AK 90, 2) DFK-R 1000, 3) DFK-BV 90
Downloads
https://media.miele.com/images/2000018/200001879/20000187987.png
Descriptions
KMDA7272FL/FR, KMDA7473FL/FR - Installation variant 1 Basis -drawing
1) DFK-AK 90, 2) DFK-R 1000
Downloads
https://media.miele.com/images/2000018/200001879/20000187999.png
Descriptions
KMDA7272FL/FR, KMDA7473FL/FR - Installation variant 12 Exhaust air - drawing
1) DFK-AK 90, 2) DFK-R 1000, 3) DFK-BH 90, 4) DFK-A, 5) DMK 150-1
Downloads
https://media.miele.com/images/2000018/200001879/20000187997.png
Descriptions
KMDA7272FL/FR, KMDA7473FL/FR - Installation variant 11 Exhaust air - drawing
1) DMK 150-1, 2) Flex hose
Downloads
https://media.miele.com/images/2000018/200001879/20000187996.png
Descriptions
KMDA7272FL/FR, KMDA7473FL/FR - Installation variant 10 Exhaust air - drawing
1) DFK-AK 90, 2) DFK-R 1000, 3) DMK 150-1
Downloads
https://media.miele.com/images/2000018/200001879/20000187995.png
Descriptions
KMDA7272FL/FR, KMDA7473FL/FR - Installation variant 9 Exhaust air - drawing
1) DFK-AK 90, 2) DFK-R 1000, 3) DFK-BH 90, 4) DFK-A, 5) DMK 150-1
Downloads

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.
