Cooker hoods - PUR 98 D Stainless steel - 1

Cooker hoods - PUR 98 D Stainless steel - 2

Island cooker hood

PUR 98 D Stainless steel

Name: PUR 98 D
Brand: Miele
SKU: 12050650
Price: 2299 GBP
Availability: InStock

with energy-efficient LED lighting and light-touch switches for easy use.

Product data sheet

£2,299.00

Delivery from £20. Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630.

Additional services

Product details

Timeless design – stainless steel canopy 898 mm wide
Powerful – 650 m3/h in Booster level
Efficient filtration-10-ply stainless-steel grease filter
Safe and easy to clean -Miele CleanCover
Suitable for every home - for extraction or recirculation

Product data sheet

Island cooker hood

Type of air guideCan be retrofitted

ColourStainless steel

Electronic controls

Booster levels1

Energy efficiency class (A+++ to D)A

Annual energy consumption in kWh/year51.80

Fluid dynamic efficiency classA

Lighting efficiency classA

Grease filtering efficiency classA

Number of dishwasher-safe stainless steel grease filters (10-ply)3

Number x W4 x 3 W

Light intensity in Lx500 lx

Colour temperature in K3000 Kelvin

Dual-action blower

AC motor

Air throughput in Level 1 (m³/h) according to EN 61591280

Air throughput in Level 2 (m³/h) according to EN 61591330

Air throughput in Level 3 (m³/h) according to EN 61591400

Air throughput in booster level 1 (m³/h)650

Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-348

Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-353

Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-357

Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-369

Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1331

Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1335

Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1339

Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1351

Air throughput in Level 1 (m³/h) according to EN 61591190

Air throughput in Level 2 (m³/h) according to EN 61591270

Air throughput in Level 3 (m³/h) according to EN 61591330

Air throughput in Booster level 1 (m³/h) according to EN 61591460

Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-357

Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-362

Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-366

Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-373

Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1340

Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1345

Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1349

Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-1356

Safety shut-off

Overall hood height for extraction mode and external in mm690–990

Overall hood height for recirculation and external in mm750–1060

Overall height for vented and external in in. (mm)690

Overall height for extraction mode and external mode cooker hoods in mm990

Overall height for recirculation in in. (mm)750

Overall height for recirculation mode cooker hoods in mm1060

Canopy width in in. (mm)898

Canopy height in in. (mm)70

Depth of hood canopy in in. (mm)598

Minimum height above electric hobs in mm450

Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm650

Net weight in kg34

Hard-wired connection

Total rated load in kW0.23

Voltage in V230

Fuse rating in A10

Frequency in Hz50

Number of phases1

Extraction ducting connection at top

Diameter of extraction ducting connection in mm150

Telescopic chimney

Non-return flap

EAN4002516585794

What's included

Easy to use and effective against grease

Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
