SmartLine element

CSDA 7001 FL Black

as downdraft extractor for extraction or recirculation operation


Colour:Black

sale price£1,799.00
Free Delivery with code FREESHIP at checkout. Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630



Product details

  • Intuitive quick selection via number sequences –Smart Select
  • Elegant design – for flush or raised installation
  • Seamlessly integrates with anySmartLine element
  • Efficient filtration-10-ply stainless-steel grease filter
  • Energy-efficient and quiet - powerfulECO motor

Product data sheet

Downdraft extractor
Type of air guideCan be retrofitted
Recirculation conversion kit (order separately)DUU 1000-2
Flat ducting components (order separately)DFK- xxxx
Flush
Frameless – surface-mounted
Operation via sensor controlsSmart Select
Digital power level display
Display colourYellow
Run-on time 5 min.
Energy efficiency class (A+++ to D)A++
Annual energy consumption in kWh/year25.3
Fluid dynamic efficiency classA
Lighting efficiency classNA
Grease filtering efficiency classB
ECO motor
Easy to clean ceramic glass
Easy-to-clean canopy interior – CleanCover
Number of dishwasher safe stainless-steel grease filters (10-ply)1
Air throughput in Level 1 (m³/h) according to EN 61591150
Air throughput in Level 2 (m³/h) according to EN 61591290
Air throughput in Level 3 (m³/h) according to EN 61591440
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-358
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1329
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1343
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1351
Sound power in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-1355
Air throughput in Level 1 (m³/h) according to EN 61591100
Air throughput in Level 2 (m³/h) according to EN 61591235
Air throughput in Level 3 (m³/h) according to EN 61591380
Air throughput in Booster level (m³/h) according to EN 61591460
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-349
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-363
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-373
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-378
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1349
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1358
Sound power in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-1363
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1334
Safety switch-off
FlameGuard
Dimensions in mm (width)120
Dimensions in mm (height)168
Dimensions in mm (depth)520
Casing height incl. connection box in mm168
Cutout dimensions in mm (width) with surface-mounted installation100
Cutout dimensions in mm (depth) with surface-mounted installation500
Inner cut-out dimensions in mm (width) with flush installation100
Inner cut-out dimensions in mm (depth) with flush installation500
Outer cut-out dimensions in mm (width) with flush installation124
Outer cut-out dimensions in mm (depth) with flush installation524
Weight in kg11
Total rated load in kW0.170
Voltage in V230
Fuse rating in A10
Number of phases1
Length of supply lead in m2
Plinth fan with vent connection
Extraction connection at rear and side
Dimensions of the exhaust ducting connector in mm222
Dimensions of the exhaust ducting connector in mm89
Ducting system to the plinth fan
Ducting system to the plinth fan
EAN4002516304906

What's included

Ducting system to the plinth fan
Ducting system to the plinth fan

User convenience

Easy to use thanks to SmartSelect
SmartSelect

Quick and intuitive: power levels and times can be selected separately for each cooking zone.


Efficiency and sustainability

The heart of every cooker hood
ECO motor

Powerful and quiet: The DC motor saves up to 70% energy compared with conventional fans.


Safety

Greater safety when combined with gas
FlameGuard

Completely safe: thanks to the FlameGuard, the gas flame cannot be drawn into the countertop extractor.


Matching products and accessories

Downloads

Operating instructions/Installation instructions
PDF
Downloads
Product sheet
PDF
Downloads
Warranty conditions
PDF
Downloads
fbx
ZIP
Downloads
rvt
ZIP
Downloads
rfa
ZIP
Downloads
ifc
ZIP
Downloads
dwg
ZIP
Downloads
Energy label
PDF
Downloads
Product fiche
PDF
Downloads
Energy label
PNG
Downloads
Energy label
Downloads

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/images/2000013/200001326/20000132669.png
Descriptions
CS 7000 FL, flush (Installation drawing)
*7+0,5 = CS7611 (Wok)
Downloads
https://media.miele.com/images/2000013/200001326/20000132666.png
Descriptions
CS 7000 FL (Installation drawing)
Installation drawings
Downloads
https://media.miele.com/images/2000013/200001331/20000133104.png
Descriptions
CSDA 7001 - flush (Installation drawing)
1) front, 2) Fan (in the plinth lying on the floor), 3) Stepped cut-out, 4) 12 mm wooden panel (not supplied as standard), 5) Air duct, 6) E-box
Downloads
https://media.miele.com/images/2000013/200001331/20000133106.png
Descriptions
CSDA 7001 - supported installation (Skizze)
1) front, 2) Fan (in the plinth lying on the floor), 3) Air duct, 4) E-Box,
Downloads
https://media.miele.com/images/2000013/200001332/20000133200.png
Descriptions
Plinth blower for CSDA 7001 (Installation drawing)
Installation drawings
