An efficient hood/extractor
An excellent product as it is highly efficient. I am very happy with my choice as the hood is top quality and stylish. Good value for money
Built-under cooker hoodSILVER
DA 1260 Stainless steel
with energy-efficient LED lighting and sliding switch for simple operation.Colour:Stainless steel
sale price£649.00
Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630
Product details
- Puristic design – space-saving solution 598 mm wide
- Powerful – 545 m3/h in Booster level
- Efficient filtration-10-ply stainless-steel grease filterLoading...
- Safe and easy to clean -Miele CleanCoverLoading...
- Suitable for every home - for extraction or recirculation
- View manufacturer details:
- Safety Information
Built-under hood
Type of air guide Can be retrofitted
Active charcoal filter (order separately) DKF 18-P
Colour Stainless steel
Mechanical controls
Slide switch
Controls Slide switch
Power levels (number without Booster level) 3
Booster levels 1
Easy-to-clean canopy interior – CleanCover
Loading...
Energy efficiency class (A+++ to D) C
Annual energy consumption in kWh/year 91.6
Fluid dynamic efficiency class D
Loading...
Lighting efficiency class A
Loading...
Grease filtering efficiency class A
Loading...
Easy-to-clean canopy interior – CleanCover
Loading...
Number of dishwasher-safe stainless steel grease filters (10-ply) 2
Loading...
Number x W 2 x 3 W
Light intensity in Lx 330 lx
Colour temperature in K 3000 Kelvin
Single-action blower
Air throughput in Level 1 (m³/h) according to EN 61591 275
Air throughput in Level 2 (m³/h) according to EN 61591 315
Air throughput in Level 3 (m³/h) according to EN 61591 355
Air throughput in Booster level 1 (m³/h) according to EN 61591 545
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 57
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 60
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 64
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 74
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 43
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 47
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 50
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 60
Air throughput in Level 1 (m³/h) according to EN 61591 165
Air throughput in Level 2 (m³/h) according to EN 61591 180
Air throughput in Level 3 (m³/h) according to EN 61591 195
Air throughput in Booster level 1 (m³/h) according to EN 61591 220
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 71
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 72
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 73
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 75
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 57
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 58
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 59
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 62
Canopy dimensions (W x H x D) in mm 598 x 125 x 500
Canopy width in in. (mm) 598
Canopy height in in. (mm) 125
Depth of hood canopy in in. (mm) 500
Minimum height above electric hobs in mm 450
Loading...
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm 650
Loading...
Net weight in kg 11.2
Length of supply lead in m 1.5
Standard plug fitted
Total rated load in kW 0.236
Voltage in V 230
Fuse rating in A 10
Frequency in Hz 50
Number of phases 1
Extraction ducting connection at top
Diameter of extraction ducting connection in mm 150
Fitting template
Non-return flap
Loading...
Deflector for recirculation
Loading...
Adapter to reduce ducting diameter from 150 mm to 125 mm Ø
EAN 4002515792186
Non-return flap
Deflector for recirculation
Adapter to reduce ducting diameter from 150 mm to 125 mm Ø
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Miele CleanCover
Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.Miele CleanCover
Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.What our customers say
Most recent reviews
Matching products and accessories
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
DA 1060, DA 1160, DA 1260 (Installation drawing)
DA 1060, DA 1160, DA 1260 (Installation drawing) POSTSCRIPT
