Product details
- Powerful – 650 m3/h in Booster level
- Efficient filtration-10-ply stainless-steel grease filterLoading...
- Safe and easy to clean -Miele CleanCoverLoading...
- Suitable for every home - for extraction or recirculation
- Manufactured with great care by
- Safety Information
Wall mounted cooker hood
Type of air guide Can be retrofitted
Recirculation conversion kit (order separately) DUW 20
Active charcoal filter (order separately) DKF 12-P
Colour Stainless steel
Possible in RAL colour (specify colour code when ordering)
Electronic controls
Controls Light-touch switches with LEDs
Power levels (number without Booster level) 3
Booster levels 1
Easy-to-clean canopy interior – CleanCover
Loading...
Energy efficiency class (A+++ to D) A
Annual energy consumption in kWh/year 49.7
Fluid dynamic efficiency class A
Loading...
Lighting efficiency class A
Loading...
Grease filtering efficiency class A
Loading...
Easy-to-clean canopy interior – CleanCover
Loading...
Number of dishwasher-safe stainless steel grease filters (10-ply) 3
Loading...
Number x W 3 x 3 W
Light intensity in Lx 450 lx
Colour temperature in K 3000 Kelvin
Dual-action blower
Air throughput in Level 1 (m³/h) according to EN 61591 265
Air throughput in Level 2 (m³/h) according to EN 61591 320
Air throughput in Level 3 (m³/h) according to EN 61591 395
Air throughput in Booster level 1 (m³/h) according to EN 61591 650
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 47
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 52
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 56
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 67
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 32
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 37
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 41
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 52
Air throughput in Level 1 (m³/h) according to EN 61591 190
Air throughput in Level 2 (m³/h) according to EN 61591 270
Air throughput in Level 3 (m³/h) according to EN 61591 330
Air throughput in Booster level 1 (m³/h) according to EN 61591 460
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 54
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 60
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 64
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3 71
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 39
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 45
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 48
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13 56
Safety shut-off
Loading...
Overall height for vented and external in in. (mm) 685
Overall height for extraction mode and external mode cooker hoods in mm 1005
Overall height for recirculation in in. (mm) 815
Overall height for recirculation mode cooker hoods in mm 1135
Canopy width in in. (mm) 898
Canopy height in in. (mm) 62
Depth of hood canopy in in. (mm) 500
Minimum height above electric hobs in mm 450
Loading...
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm 650
Loading...
Net weight in kg 25
Length of supply lead in m 1.5
Standard plug fitted
Total rated load in kW 0.229
Voltage in V 230
Fuse rating in A 10
Frequency in Hz 50
Number of phases 1
Extraction ducting connection at top
Extraction connection at top and rear
Diameter of extraction ducting connection in mm 150
Telescopic chimney
Loading...
Non-return flap
Loading...
EAN 4002515752791
Non-return flap
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Miele CleanCover
Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Miele CleanCover
Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.
Always on the safe side
Safety switch-off
Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.
Matching products and accessories
Downloads
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
PUR92W Living, PUR98W, DA419-6, DA419-7 (Installation drawing)
1) Extraction, 2) Recirculation, 3) Ventilation grille at top for recirculation, 4+5) Installation cut-out (5 not required for recirculation) - 1.Installation and recycling options available at checkout. For installation of built-in appliances please call 0330 160 6630
