PWM 507 [EL DP]
Professional washing machine, Little Giants, electric heating, drain pump and programmes specific to the target group. Performance 7 kg in 59 min.
- Drum volume 64 l, load size 7 kg
- 22 % less water consumption and 28 % less energy consumption*Based on the Coloured items 60 °C programme with a warm water connection, compared to predecessor.
- Tested for intensive use – unparalleled Miele qualityUnparalleled Miele quality
Miele Professional stands for high-performance laundry machines that professional users can always rely upon. High-quality materials that undergo outstanding craftsmanship, but are also subject to intensive testing, are what guarantee Miele’s renowned standards of quality. Stringent tests are performed on every single machine, even during the production stage. - Language-neutral fascia panel with rotary control – M SelectM Select control system
Fast, direct selection of the wash programme and effortless access to additional functions and settings. - Thorough cleaning with professional wash programmesThorough cleaning w. professional wash programmes
High-performance wash programmes make it possible to remove even stubborn stains reliably.
Product benefits
Proven hygiene
Effective against viruses – scientifically proven
Our washing machines in the Little Giants series remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology can be found under the following link: https://www.miele.com/media/ex/com/Professional/Pruefberichte_Virussiegel/LittleGiant_Viruswirksamkeit_Testkriterien_Virus_effectiveness_test_criteria_2022_1.pdf
EcoSpeed – patented wash rhythm*European patent: EP 1354997 B1
A new balance of mechanical action and water usage
Intensive cleaning with reduced water consumption due to optimised changes in speed.
Stainless steel flange*European patent: EP 3631075 Chinese patent: CN 201880035738South Korean patent: KR 10-2314826 US patent: US 11136704
Professional appliance technology
Long service life due to high resistance to aggressive cleaning agents.
Commercial shock absorbers
For optimum smooth running
Incredibly smooth running even at high spin speeds with professional shock absorbers lasting for 30,000 hours.
Easy to understand symbols
Language-neutral operation
The control panel is characterised by logically arranged and easy to understand symbols.
Pre-ironing
Reduced creasing
The “Pre-ironing” function reduces the need for ironing.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Exclusive to Miele
WiFiConn@ct
Future-proof connections
Simple networking via WiFiConn@ct: connect via smartphone/tablet and app* and retrieve status updates.The Mobile app is available separately – its availability depends on the country or region.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Large capacity
More space
Miele Professional washer-extractors have a large capacity drum to accommodate large loads of laundry.
EasyDos
Optimised dispensing of liquid media
Dispensing of liquid detergent can be set individually to suit requirements.
Precise automatic load recognition
Efficient savings
Water and energy consumption are automatically adjusted for the load size.
Efficient hot water connection
Quick and economical
Connection to a hot water supply enables excellent savings in time and energy with minimal effort.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Proven hygiene
Effective against viruses – scientifically proven
Our washing machines in the Little Giants series remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology can be found under the following link: https://www.miele.com/media/ex/com/Professional/Pruefberichte_Virussiegel/LittleGiant_Viruswirksamkeit_Testkriterien_Virus_effectiveness_test_criteria_2022_1.pdf
High temperature consistency
We keep our promises
For reliable cleaning results and maximum hygiene, the temperature of the washing water is monitored constantly.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
EcoSpeed – patented wash rhythm*European patent: EP 1354997 B1
A new balance of mechanical action and water usage
Intensive cleaning with reduced water consumption due to optimised changes in speed.
Precisely controlled water consumption
Every drop counts
The flow meter monitors the volume of water intake precisely for maximum efficiency.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Stainless steel flange*European patent: EP 3631075 Chinese patent: CN 201880035738South Korean patent: KR 10-2314826 US patent: US 11136704
Professional appliance technology
Long service life due to high resistance to aggressive cleaning agents.
Commercial shock absorbers
For optimum smooth running
Incredibly smooth running even at high spin speeds with professional shock absorbers lasting for 30,000 hours.
Powerful heater elements
Truly powerful
The washer-extractors are equipped with powerful heater elements for heating water quickly.
Excellent durability
Ultimate quality
Professional technology ensures excellent reliability and durability for daily work routine.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Easy to understand symbols
Language-neutral operation
The control panel is characterised by logically arranged and easy to understand symbols.
Pre-ironing
Reduced creasing
The “Pre-ironing” function reduces the need for ironing.
Exclusive to Miele
Patented CapDosing*European patent: EP 2 365 120
Fast and reliable dispensing in special cases
Infrequently used detergents are easily dispensed in capsule form.
Countdown indicator
An eye on the time
After the programme has started, the display shows the cycle time remaining.
Drum lighting
Let there be light
No laundry item is overlooked when unloading thanks to the perfectly lit honeycomb drum.
Add laundry
Open the door and add laundry
Did you forget an item of laundry? Don’t worry – simply open the door and add the laundry.*It is possible to add laundry within the first few minutes of starting a programme.
Subject to technical changes; no liability accepted for the accuracy of the information given! Figures as examples for showing the product benefit.
Product details
PWM 507 [EL DP]
EAN 4002516363767 / Article number 51507353GB / Material number 11105770
EAN 4002516363767 / Article number 51507353GB / Material number 11105770
Construction type | Front-loader, stackable |
---|---|
Range | Performance |
Front | Stainless steel |
Control panel colour | Stainless steel |
Load in kg | 7 |
Drum volume in l | 64 |
Door opening [Ø] in mm Large drum opening Large drum opening for fast, ergonomic loading and unloading ensures smooth operation. | 300 |
Door opening angle in degrees | 167 |
Door hinge | right |
Maintenance-free synchronous motor | |
Honeycomb drum with perforated drum rear panel made of stainless steel |
Tested virucidal efficacy | Proven hygiene Our washing machines in the Little Giants series remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology can be found under the following link: https://www.miele.com/media/ex/com/Professional/Pruefberichte_Virussiegel/LittleGiant_Viruswirksamkeit_Testkriterien_Virus_effectiveness_test_criteria_2022_1.pdf |
---|---|
Proven hygiene | |
Specific water consumption for cold water connection in l/kg Note In the Cottons 60°C programme with connection to cold water. | 7 |
Specific energy consumption for cold water connection in kWh/kg Note In the Cottons 60°C programme with connection to cold water. | 0.14 |
Specific water consumption for hot water connection in l/kg Note In the Cottons 60 °C programme with connection to hot and cold water, hot rinse. | 6.6 |
Specific energy consumption for hot water connection in kWh/kg Note In the Cottons 60 °C programme with connection to hot and cold water, hot rinse. | 0.06 |
Water consumption with cold water connection in l Note In the Cottons 60°C programme with connection to cold water. | 49 |
Energy consumption with cold water connection in kW Note In the Cottons 60°C programme with connection to cold water. | 0.98 |
Programme duration in minutes with cold water connection Note In the Cottons 60°C programme with connection to cold water. | 69 |
Water consumption with hot water connection in l Note In the Cottons 60 °C programme with connection to hot and cold water, hot rinse. | 46 |
Energy consumption with hot water connection in kW Note In the Cottons 60 °C programme with connection to hot and cold water, hot rinse. | 0.44 |
Programme duration in minutes with cold water and hot water connection Note In the Cottons 60 °C programme with connection to hot and cold water, hot rinse. | 59 |
Residual moisture with cold rinse in % | 48 |
Residual moisture with hot rinse in % | 45 |
Spin speed in rpm | 1600 |
g factor | 704 |
Tested operating hours Note Our machines undergo intensive testing under laboratory conditions. The actual operating hours may vary depending on actual usage behaviour, maintenance and care of the machine. | 30000 |
Control system | M Select |
---|---|
Programmability | programmable |
Max. delay start in h | 24 Delay start up to 24 hours The programme start time can be pre-set up to 24 hours in advance for efficient planning. |
Time left display | |
Programme sequence indicator | |
Control panel with easy-to-understand symbols | |
Language can be selected easily at any time |
Detergent drawer | 3 compartments |
---|---|
CapDosing | Patented CapDosing* Infrequently used detergents are easily dispensed in capsule form.European patent: EP 2 365 120 |
Flexible dispensing adapter (optional) | |
Maximum number of connections for liquid dispenser pumps [number] | 6 EasyDos Dispensing of liquid detergent can be set individually to suit requirements. |
Empty sensor |
Heating type | Electric |
---|---|
Electrical connection | 230V~ |
Heater rating in kW | 2.65 |
Total connected load in kW | 2.85 |
Fuse rating in A | 13 |
Electrical connection | 2N~ 400V 50HZ |
---|---|
Heater rating in kW | 5.3 |
Total connected load in kW | 5.5 |
Fuse rating in A | 13 |
Cold water [number] | 1x 1/2" hose w/ 3/4" th. union |
---|---|
Hot water [number] | 1x 1/2" hose w/ 3/4" th. union |
Drain pump | DN 22 |
External dimensions, height in mm | 850 |
---|---|
External dimensions, width in mm | 605 |
External dimensions, depth in mm | 714 |
External dimensions, gross height in mm Note Including packaging | 944 |
External dimensions, gross width in mm Note Including packaging | 660 |
External dimensions, gross depth in mm Note Including packaging | 768 |
Net weight in kg | 100 |
Gross weight in kg Note Including packaging | 104 |
Maximum floor load in N | 2820 |
Emission sound pressure level in the workplace Emission sound pressure level in the workplace The emission sound pressure level is a value given to the noise created by the machine. Miele Professional commercial laundry machines have very low noise levels. | <lt/>70 dB(A) re 20 µPa |
---|---|
Heat dissipation into the room in MJ/h Heat output into the room During operation, laundry machines release heat into the surrounding area. The released amount of heat/time depends on the set temperatures and the intensity of use. The stated maximum value can be used to control the temperature of the area or to calculate an increase in room temperature. | 1 |
3-dimensional imbalance monitoring | |
---|---|
Commercial shock absorbers | |
Hard-wearing stainless-steel flange | Stainless steel flange* Long service life due to high resistance to aggressive cleaning agents.European patent: EP 3631075 Chinese patent: CN 201880035738South Korean patent: KR 10-2314826 US patent: US 11136704 |
Disinfection rinse | |
EcoSpeed | EcoSpeed – patented wash rhythm* Intensive cleaning with reduced water consumption due to optimised changes in speed.European patent: EP 1354997 B1 |
Pre-ironing | |
Efficient drum rib technology | |
Temperature monitoring | |
Special heater element | |
Automatic load control | |
Flow meter | |
LED drum lighting, class 1 | |
Communication slot | |
Add laundry | Add laundry Did you forget an item of laundry? Don’t worry – simply open the door and add the laundry.*It is possible to add laundry within the first few minutes of starting a programme. |
Machine-independent accessories |
Load size for the “Eco 40–60” programme in kg | 7 |
---|---|
Energy efficiency class (A–G) | A |
Spin efficiency class (A–G) | A |
Weighted energy consumption per 100 cycles in the “Eco 40–60” programme in kWh | 45 |
Weighted water consumption per cycle in the “Eco 40–60” programme in l | 37 |
Airborne noise emission rating (spin cycle) (A–D) | A |
Airborne noise emission during spin cycle in dB(A) re 1 pW | 72 |
Airborne noise emission during spin cycle in dB(A) re 1 pW | 199 |
Recycling rate in % | 95 |
Payment system (optional) | |
---|---|
Optical interface for service access | |
Peak-load negotiation / energy management (optional) | |
LAN/WiFi module (optional) | |
WiFiConn@ct | WiFiConn@ct Simple networking via WiFiConn@ct: connect via smartphone/tablet and app* and retrieve status updates.The Mobile app is available separately – its availability depends on the country or region. |
CE | |
---|---|
VDE-EMC | |
VDE | |
Splash-proof safety rating IPX4 | |
WRAS | |
UKCA | |
WEEE | |
Complies with Machinery Directive 2006/42/EC |
