PWM 307 [EL DP]
Professional washing machine, Little Giants, electric heating, drain pump
and the shortest cycle time of 59 minutes for high laundry throughput.
- Drum volume 64l, load capacity 7.0kg
- Tested for intensive use – unparalleled Miele qualityUnparalleled Miele quality
Miele Professional stands for high-performance laundry machines that professional users can always rely upon. High-quality materials that undergo outstanding craftsmanship, but are also subject to intensive testing, are what guarantee Miele’s renowned standards of quality. Stringent tests are performed on every single machine, even during the production stage. - Language-neutral fascia panel with rotary control – M SelectM Select control system
Fast, direct selection of the wash programme and effortless access to additional functions and settings. - Thorough cleaning with standard washing programmes
Product benefits
Safe disinfection
Maximum hygiene assurance
Disinfection programmes ensure reliable levels of hygiene.
The hygiene certificate can be found under “Downloads”.*Model-dependent
The hygiene certificate can be found under “Downloads”.*Model-dependent
Proven hygiene
Effective against viruses – scientifically proven
Our washing machines in the Little Giants series remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology can be found at the following link: https://miele.com/LittleGiants
EcoSpeed – patented wash rhythm*European patent: EP 1354997 B1
A new balance of mechanical action and water usage
Intensive cleaning with reduced water consumption due to optimised changes in speed.
Commercial shock absorbers
For optimum smooth running
Incredibly smooth running even at high spin speeds with professional shock absorbers lasting for 30,000 hours.
Easy to understand symbols
Language-neutral operation
The control panel is characterised by logically arranged and easy to understand symbols.
Precise automatic load recognition
Efficient savings
Water and energy consumption are automatically adjusted for the load size.
Large capacity
More space
Miele Professional washer-extractors have a large capacity drum to accommodate large loads of laundry.
High temperature consistency
We keep our promises
For reliable cleaning results and maximum hygiene, the temperature of the washing water is monitored constantly.
Safe disinfection
Maximum hygiene assurance
Disinfection programmes ensure reliable levels of hygiene.
The hygiene certificate can be found under “Downloads”.*Model-dependent
The hygiene certificate can be found under “Downloads”.*Model-dependent
Proven hygiene
Effective against viruses – scientifically proven
Our washing machines in the Little Giants series remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology can be found at the following link: https://miele.com/LittleGiants
Precisely controlled water consumption
Every drop counts
The flow meter monitors the volume of water intake precisely for maximum efficiency.
EcoSpeed – patented wash rhythm*European patent: EP 1354997 B1
A new balance of mechanical action and water usage
Intensive cleaning with reduced water consumption due to optimised changes in speed.
Enamelled front
Extremely robust
The enamel front is resistant to scratches, acid, and corrosion, and is easy to clean.
Powerful heater elements
Truly powerful
The washer-extractors are equipped with powerful heater elements for heating water quickly.
Excellent durability
Ultimate quality
Professional technology ensures excellent reliability and durability for daily work routine.
Commercial shock absorbers
For optimum smooth running
Incredibly smooth running even at high spin speeds with professional shock absorbers lasting for 30,000 hours.
Countdown indicator
An eye on the time
After the programme has started, the display shows the cycle time remaining.
Easy to understand symbols
Language-neutral operation
The control panel is characterised by logically arranged and easy to understand symbols.
A wide range of accessories*All accessories can be purchased as an option.
Lots of added extras
Consistently perfect work processes and efficiency - with a large selection of practical accessories.
Patented CapDosing*European patent: EP 2 365 120
Fast and reliable dispensing in special cases
Infrequently used detergents are easily dispensed in capsule form.
Add laundry
Open the door and add laundry
Did you forget an item of laundry? Don’t worry – simply open the door and add the laundry.*It is possible to add laundry within the first few minutes of starting a programme.
Product details
PWM 307 [EL DP]
EAN 4002516413813 / Article number 51307172GB / Material number 11693340
EAN 4002516413813 / Article number 51307172GB / Material number 11693340
| Construction type | Front-loader, stackable Washer-dryer stack High performance in the smallest space: Installation as washer-dryer stack requires less than 0.5 m² floor space. |
|---|---|
| Range | Evolution |
| Front | Lotos white, enamelled Enamelled front The enamel front is resistant to scratches, acid, and corrosion, and is easy to clean. |
| Load in kg | 7.0 |
| Drum volume in l | 64 |
| Door opening [Ø] in mm Large drum opening Large drum opening for fast, ergonomic loading and unloading ensures smooth operation. | 300 |
| Door opening angle in degrees | 167 |
| Door hinge | right |
| Maintenance-free synchronous motor | |
| Honeycomb drum with perforated drum rear panel |
| Proven hygiene | Proven hygiene Our washing machines in the Little Giants series remove more than 99.9 %* of all viruses (including coronaviruses).A description of the relevant methodology can be found at the following link: https://miele.com/LittleGiants |
|---|---|
| Specific water consumption for cold-water connection in l/kg Note In the Cottons 60°C programme with connection to cold water. | 7.00 |
| Specific energy consumption for cold-water connection in kWh/kg Note In the Cottons 60°C programme with connection to cold water. | 0.14 |
| Water consumption with cold water connection in l Note In the Cottons 60°C programme with connection to cold water. | 49.0 |
| Energy consumption with cold water connection in kWh Note In the Cottons 60°C programme with connection to cold water. | 0.98 |
| Programme duration in minutes with cold water connection Note In the Cottons 60°C programme with connection to cold water. | 59 |
| Residual moisture with cold rinse in % Note In the Cottons 60°C programme with connection to cold water. | 48 |
| Spin speed in rpm | 1,600 |
| g factor | 704 |
| Tested operating hours Note Our machines undergo intensive testing under laboratory conditions. The actual operating hours may vary depending on actual usage behaviour, maintenance and care of the machine. | 30,000 |
| Control system | M Select M Select control system Fast, direct selection of the wash programme and effortless access to additional functions and settings. |
|---|---|
| Programmability | programmable Programmable controls Whenever needed: Programmable controls enable perfect adaptation to suit individual requirements. |
| Max. delay start in h | 24 Delay start up to 24 hours The programme start time can be pre-set up to 24 hours in advance for efficient planning. |
| Time left display | |
| Programme sequence indicator | |
| Control panel with easy-to-understand symbols | |
| Language can be selected easily at any time |
| Detergent drawer | 3 compartments |
|---|---|
| CapDosing | Patented CapDosing* Infrequently used detergents are easily dispensed in capsule form.European patent: EP 2 365 120 |
| Heating type | Electrical |
|---|---|
| Electrical connection | 230V~ 50HZ |
| Heater rating in kW | 2.30 |
| Total connected load in kW | 2.50 |
| Fuse rating in A | 13 |
| Cold water [number] | 1x 1/2" hose w/ 3/4" th. union |
|---|---|
| Drain pump | DN 22 Drain pump The built-in drain pump with up to 1 metre delivery height ensures easy removal of suds. |
| External dimensions, net height in mm | 850 |
|---|---|
| External dimensions, net width in mm | 596 |
| External dimensions, net depth in mm | 714 |
| External dimensions, gross height in mm Note Including packaging | 944 |
| External dimensions, gross width in mm Note Including packaging | 660 |
| External dimensions, gross depth in mm Note Including packaging | 768 |
| Net weight in kg | 98 |
| Gross weight in kg Note Including packaging | 102 |
| Maximum floor loading in N Maximum floor bearing capacity Maximum floor bearing capacity states the maximum force (N) that the surface on which the machine is installed can tolerate. This maximum load bearing capacity is the result of adding up the weight of the machine, the load and the water in it, as well as the dynamic forces that occur during operation. | 2820 |
| Emissions – sound pressure at workplace Emission sound pressure level in the workplace The emission sound pressure level is a value given to the noise created by the machine. Miele Professional commercial laundry machines have very low noise levels. | <70 dB(A) re 20 µPa |
|---|---|
| Heat dissipation into the room in MJ/h Heat output into the room During operation, laundry machines release heat into the surrounding area. The released amount of heat/time depends on the set temperatures and the intensity of use. The stated maximum value can be used to control the temperature of the area or to calculate an increase in room temperature. | 1.00 |
| 3-dimensional imbalance monitoring | |
|---|---|
| Commercial shock absorbers | |
| Hard-wearing stainless-steel flange | |
| Disinfection rinse | |
| EcoSpeed | EcoSpeed – patented wash rhythm* Intensive cleaning with reduced water consumption due to optimised changes in speed.European patent: EP 1354997 B1 |
| Pre-ironing | |
| Efficient drum rib technology | |
| Temperature monitoring | |
| Special heater element | |
| Automatic load control | |
| Flow meter | |
| Add laundry | Add laundry Did you forget an item of laundry? Don’t worry – simply open the door and add the laundry.*It is possible to add laundry within the first few minutes of starting a programme. |
| Machine-independent accessories | A wide range of accessories* Consistently perfect work processes and efficiency - with a large selection of practical accessories.All accessories can be purchased as an option. |
| Load size for the “Eco 40–60” programme in kg | 7 |
|---|---|
| Energy efficiency class (A–G) | A |
| Spin efficiency class (A–G) | A |
| Weighted energy consumption per 100 cycles in the “Eco 40–60” programme in kWh | 45 |
| Weighted water consumption per cycle in the “Eco 40–60” programme in l | 37 |
| Airborne noise emission rating (spin cycle) (A–D) | A |
| Airborne noise emission during spin cycle in dB(A) re 1 pW | 72 |
| Programme running time in the “Eco 40–60” programme in min | 199 |
| Recycling rate in % | 95 |
| Payment system (optional) | |
|---|---|
| Optical interface for service access |
| CE | |
|---|---|
| VDE-EMC | |
| VDE | |
| Splash protection IPX4 | |
| WRAS | |
| WEEE | |
| Complies with Machinery Directive 2006/42/EC |
