DAR 1235
Wall mounted cooker hood for perfectly combining with Range Cookers or Range Tops.
Your exclusive advantages
Stainless steel baffle filter
High quality and extremely functional
Convenient cleaning: The high-quality metal grease filters are dishwasher-proof and extremely durable.
LED ClearView lighting
Powerful lighting with minimum energy consumption
Environmentally friendly and very long lasting: With up to 3 W they illuminate the hob evenly with a warm light.
Rotary controls
Discreetly integrated
Matching convenience: Rotary control allow intuitive and easy operation of fan power and LED lighting.
Temperature sensor
Permanent safety
Continuous monitoring: the temperature sensor ensures safety and prevents unnecessary energy consumption.
Miele CleanCover
Convenience and safety in detail
Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.
Features depend on model – images are only examples and used for explanation purposes
Features (1)
Miele CleanCover
Convenience and safety in detail
Protection and easy cleaning: the smooth concealed surface prevents contact with electrical components and motor.
User convenience (1)
Rotary controls
Discreetly integrated
Matching convenience: Rotary control allow intuitive and easy operation of fan power and LED lighting.
Maintenance (1)
Stainless steel baffle filter
High quality and extremely functional
Convenient cleaning: The high-quality metal grease filters are dishwasher-proof and extremely durable.
Efficiency and sustainability (2)
LED ClearView lighting
Powerful lighting with minimum energy consumption
Environmentally friendly and very long lasting: With up to 3 W they illuminate the hob evenly with a warm light.
Temperature sensor
Permanent safety
Continuous monitoring: the temperature sensor ensures safety and prevents unnecessary energy consumption.
What’s included
Product data sheet
Construction type
| Wall mounted cooker hood | • |
Operating modes
| Type of air guide | Convertible |
User convenience
| Electronic controls | • |
| Rotary knob | • |
| Power levels (number without Booster level) | 3 |
| Booster level | • |
| Temperature sensor | • |
Cleaning convenience
| Easy-to-clean canopy interior – CleanCover | • |
| Dishwasher-safe grease collection channel | • |
Efficiency and sustainability
| Annual energy consumption in kWh/year | 68.40 |
| B | |
| Annual energy consumption in kWh/year | 68.40 |
| Annual energy consumption in kWh/year | 68.40 |
| Fluid dynamic efficiency class | B |
| Lighting efficiency class | A |
| Grease filtering efficiency class | C |
Filter system
| Number of dishwasher-safe stainless steel filters | 3 |
Lighting
| LED | • |
| Number x W | 3 x 3 W |
Fan
| Dual-action fan | • |
| AC motor | • |
Extraction
| Air throughput in Level 1 (m³/h) according to EN 61591 | 200 |
| Air throughput in Level 2 (m³/h) according to EN 61591 | 300 |
| Air throughput in Level 3 (m³/h) according to EN 61591 | 400 |
| Air throughput in Booster level (m³/h) according to EN 61591 | 650 |
| Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 | 39 |
| Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 | 48.00 |
| Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 | 54.00 |
| Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3 | 67 |
| Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 | 25.00 |
| Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 | 34.00 |
| Sound pressure in Level 3 (dB(A) re 20 µPa) | 40.00 |
| Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 | 53.00 |
Recirculation
| Air throughput in Level 1 (m³/h) according to EN 61591 | 200 |
| Air throughput in Level 2 (m³/h) according to EN 61591 | 300 |
| Air throughput in Level 3 (m³/h) according to EN 61591 | 400 |
| Air throughput in Booster level (m³/h) according to EN 61591 | 650 |
| Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3 | 44.00 |
| Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3 | 52.00 |
| Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3 | 59.00 |
| Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-3 | 71.00 |
| Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13 | 29.00 |
| Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13 | 37.00 |
| Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13 | 44.00 |
| Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-13 | 57.00 |
Safety
| Safety switch-off | • |
Technical data
| Canopy width in mm | 914 |
| Canopy height in mm | 457 |
| Canopy depth in mm | 611 |
| Minimum height above electric hobs in mm | 450 |
| Minimum height above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW) in mm | 650 |
| Net weight in kg | 36.00 |
| Length of supply lead in m | 1.00 |
| Standard plug fitted | • |
| Total rated load in kW | 0.21 |
| Voltage in V | 230 |
| Fuse rating in A | 15 |
| Number of phases | 1 |
Installation notes
| Extraction ducting connection at top | • |
| Extraction ducting connection at rear | • |
| Extraction ducting connection on side | • |
| Extraction ducting connection at top, rear, and si | • |
| Diameter of extraction ducting connection in mm | 150 |
Optional accessories
| Chimney cover⁴ (H: 152 mm) | DRDC 3606 |
| Chimney cover⁴ (H: 305 mm) | DRDC 3612 |
| Chimney cover⁴ (H: 457 mm) | DRDC 3618 |
| Chimney cover⁴ (H: 610 mm) | DRDC 3624 |
| Recirculation mode conversion kit | DRUU 36 |
| Rear-wall panel (W: 913 mm) | RBS 36 |
| Rear-wall panel (W: 1218 mm) | RBS 48 |
| Active charcoal filter | DKF 24-1 |
Supplementary products and accessories
Downloads, CAD & Apps
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions
DAR1235 (installation drawing)
