DAD 4840 Black Levantar
£2,299.00
1 . Free delivery on all orders over £15.00. A delivery charge of £6.00 is applied to orders under £15.00. Installation of new appliances and recycling of old appliances is available at an extra charge. For all built-in appliances please call 0330 160 6630 to arrange this.
[1]
Dealer search

DAD 4840 Black Levantar

Downdraft extractor system in elegant matt black design and with intuitive SmartControl operation

  • Subject to technical changes; no liability accepted for the accuracy of the information given. See General Terms and Conditions in footer for additional details.

Your exclusive advantages

Features depend on model – images are only examples and used for explanation purposes

Product data sheet

Downdraft extractor system
Type of air guideConvertible
ColourMatt black
Edge extraction
Miele@home
Automatic function Con@ctivity 3.0 (WiFi)
Electronic controls
Run-on time 5/15 min.
Grease filter saturation indicator
Grease filter saturation indicator programmable
Active charcoal filter saturation indicator programmable
Motor-operated cooker hoods
Easy-to-clean canopy interior – CleanCover
Energy efficiency class (A+++ to D)A
Annual energy consumption in kWh/year41.60
Fluid dynamic efficiency classA
Lighting efficiency classA
Grease filtering efficiency classB
PowerManagement system
ECO motor
Number of dishwasher-safe stainless steel grease filters (10-ply)2
Number x W1 x 11,2 W
Light intensity in Lx400 lx
Colour temperature in K3500 Kelvin
Dual-action blower
DC motor
Air throughput in Level 1 (m³/h) according to EN 61591200
Air throughput in Level 2 (m³/h) according to EN 61591340
Air throughput in Level 3 (m³/h) according to EN 61591440
Air throughput in Booster level (m³/h) according to EN 61591600
Air throughput in Booster level (m³/h) according to EN 61591640
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-344.00
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-357.00
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-362.00
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-370.00
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-372.00
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1330.00
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1343.00
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1349.00
Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-1356.00
Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-1358.00
Air throughput in Level 1 (m³/h) according to EN 61591160
Air throughput in Level 2 (m³/h) according to EN 61591320
Air throughput in Level 3 (m³/h) according to EN 61591415
Air throughput in Booster level (m³/h) according to EN 61591520
Air throughput in Booster level (m³/h) according to EN 61591555
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-350.00
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-364.00
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-369.00
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-375.00
Sound power in Booster level (dB(A) re 1 pW) acc. to EN 60704-376.00
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-1337.00
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-1350.00
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-1356.00
Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-1361.00
Sound pressure in Booster level (dB(A) re 20 µPa) acc. to EN 60704-2-1362.00
Safety shut-off
Single-ply safety glass (ESG)
Canopy width in in. (mm)916
Depth of hood canopy in in. (mm)170
Net weight in kg34.00
Length of supply lead in m1.50
Standard plug fitted
Total rated load in kW0.25
Voltage in V230
Fuse rating in A10
Frequency in Hz50
Number of phases1
Diameter of extraction ducting connection in mm150
Optimal combination with hobKM 7684 FL; KM 7689 FL
Active charcoal filterNo
Downloads, CAD & Apps
  • Operating instructions/Installation instructions
    PDF
  • EU declaration of conformity
    PDF
  • Installation plan
    PDF
  • Warranty conditions
    PDF
  • Warranty conditions
    PDF
  • fbx
    ZIP
  • fbx
    ZIP
  • ifc
    ZIP
  • ifc
    ZIP
  • dwg
    ZIP
  • dwg
    ZIP
  • rfa
    ZIP
  • rfa
    ZIP
  • rvt
    ZIP
  • rvt
    ZIP
  • Product fiche
    PDF
Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!
Descriptions

DAD4840, Installation drawings

1. Stepped cutout for flush-fit installation in stone worktops (granite

marble).

2. Ensure that materials are sufficiently stable.

3. Cut-out off-centre.

Exhaust duct Ø 150 mm.

* Only required when flat ducting is laid under cabinets or the DUU 600 recirculation box is used.

Descriptions

DAD4840, DAD4940 - DUP150, Installation version 1, Installation drawings

Descriptions

DAD4840, DAD4940 - DUU600 Plinth box, Installation version 2, Installation drawings

Descriptions

DAD4840, DAD4940, overlying - AP600 mm, Side view, Installation drawings

① Only required when flat ducting is laid under cabinets or the DUU 600 recirculation box is used.

② Exhaust duct Ø 150 mm.

Descriptions

DAD4840, DAD4940 - DUU 600 Plinth box, Installation version 2, Installation drawings

① DFK-AK 90

② DFK-R 1000

③ DFK-BH-45

④ DUU 600

Descriptions

DAD4840, DAD4940, flush - AP600 mm, Top view, Installation drawings

① Exhaust duct Ø 150 mm.

Descriptions

DAD4840, DAD4940 - DMK150-1 wall box, Installation version 3, Installation drawings

① DFK-AK 90

② DFK-R 1000

③ DFK-BH 45

④ DFK-A

⑤ DMK 150-1

Descriptions

DAD4840, DAD4940, overlying AP <gt/> 600 mm, Side view, Installation drawings

① Only required when flat ducting is laid under cabinets or the DUU 600 recirculation box is used.

② Exhaust duct Ø 150 mm.

Descriptions

DAD4840, DAD4940, flush AP <gt/> 600 mm, Side view, Installation drawings

① Only required when flat ducting is laid under cabinets or the DUU 600 recirculation box is used.

② Exhaust duct Ø 150 mm.

Descriptions

DAD4840, DAD4940, flush AP <gt/> 600 mm, Top view, Installation drawings

① Exhaust duct Ø 150 mm.

Descriptions

DAD4840, Detail, Installation drawings

① Stepped cutout for flush-fit installation in stone worktops (granite

marble).

② Ensure that materials are sufficiently stable.

③ Cut-out off-centre. Exhaust duct Ø 150 mm.

„ Only required when flat ducting is laid under cabinets or the DUU 600 recirculation box is used.

Descriptions

DAD4840, DAD4940 - DUP150, Installation version 1, Installation drawings

Descriptions

DAD4840, DAD4940 - DUP150, Installation version 1, Installation drawings

① DUP 150

Descriptions

DAD4840, DAD4940 - DUP150, Installation version 1, Installation drawings

① DUP 150
